- Place of Origin: China
- Brand Name: BAIMAI
- Model Number: PT125 (6015)
Quick Details
| Feature: | Tower Crane | Condition: | New | Application: | Costrucation |
| Rated Loading Capacity: | 1.50 Ton | Rated Lifting Moment: | 1250KN/M | Max. Lifting Load: | 8 Ton |
| Max. Lifting Height: | 200m | Span: | 60m | Place of Origin: | Shandong China (Mainland) |
| Brand Name: | BAIMAI | Model Number: | PT125 | Certification: | ISO9001-2008 |
| Warranty: | Lifetime Warranty | After-sales Service Provided: | No overseas service provided | Motor: | JiangTe |
| Working temperature: | -20- 40 | Tib Load: | 1.50 Ton | Independ setting height: | 58m |
- Place of Origin: China
- Brand Name: BAIMAI
- Model Number: PT125 (6015)
Main Technical Parameters
Name | Unit | Parameters | |||||||
Nominal hoisting moment | kN.m | 1600 | |||||||
Max. Hoisting weight | t | 10 | |||||||
Rated hoisting weight at jib nose | t | 1.8 | |||||||
Working radius | m | 2.5—65 | |||||||
Height (m) | Anchoring | M | 50 | ||||||
Climbing | m | 150 | |||||||
Hoisting speed | Magnification | 2X | 4X | ||||||
Hoisting speed | M/min | 8 | 40 | 80 | 4 | 20 | 40 | ||
Max. Hoisting weight | t | 3 | 3 | 1.5 | 6 | 6 | 3 | ||
Swing speed | R/min | 0.7 | |||||||
Radius changing speed | M/min | 22/44 | |||||||
Top rising speed | M/min | 0.5 | |||||||
Tower crane weight | Net weight (anchoring) | T | |||||||
Ballast weight | T | 12 | |||||||
Total weight (anchoring) | T | ||||||||
Working swing radius | M | ||||||||
Rear swing radius | M | 12.06 | |||||||
Maximum working wind speed | M/S | 20 | |||||||
Maximum wind speed for top rising | M/S | 13 | |||||||
Ambient temperature | |||||||||
