- Place of Origin: CN
- Brand Name: BAIMAI
- Model Number: qtz80(6010)
Quick Details
Feature: | Tower Crane | Condition: | New | Application: | Vertical lift machine building industry |
Rated Loading Capacity: | 8t | Rated Lifting Moment: | 800kn/m | Max. Lifting Load: | 8T |
Max. Lifting Height: | 150 | Span: | 2.5-56m | Place of Origin: | Shandong China (Mainland) |
Brand Name: | baimai | Model Number: | QTZ80 | Certification: | ISO ce |
Warranty: | Steel structure warranty for life | After-sales Service Provided: | Overseas third-party support available | color: | custom |
- Place of Origin: CN
- Brand Name: BAIMAI
- Model Number: qtz80(6010)
Main Technical Parameters
Name | Unit | Parameters | |||||||
Nominal hoisting moment | kN.m | 3150 | |||||||
Max. Hoisting weight | t | 16 | |||||||
Rated hoisting weight at jib nose | t | 3 | |||||||
Working radius | m | 2.5—70 | |||||||
Height (m) | Anchoring | M | 60 | ||||||
Climbing | m | 2200 | |||||||
Hoisting speed | Magnification | 2X | 4X | ||||||
Hoisting speed | M/min | 8 | 40 | 80 | 4 | 20 | 40 | ||
Max. Hoisting weight | t | 3 | 3 | 1.5 | 6 | 6 | 3 | ||
Swing speed | R/min | 0.7 | |||||||
Radius changing speed | M/min | 22/44 | |||||||
Top rising speed | M/min | 0.5 | |||||||
Tower crane weight | Net weight (anchoring) | T | |||||||
Ballast weight | T | 12 | |||||||
Total weight (anchoring) | T | ||||||||
Working swing radius | M | ||||||||
Rear swing radius | M | 12.06 | |||||||
Maximum working wind speed | M/S | 20 | |||||||
Maximum wind speed for top rising | M/S | 13 | |||||||
Ambient temperature | °C | -20~ 40 |
